RCD
Spring isolators with multi-degree restrainer are designed to provide high vibration isolation and energy dissipation for machinery and equipment. They combine the elastic properties of springs with high energy absorption capabilities of a secondary elastomeric support. These dampers are particularly effective in applications where significant reduction of shock is required such as power presses, shearing machines, Press Brake etc.

Documents
13 Models
| Model | Load (Kg) | Free Height H | Bolt Size | Top Plate Axb (Mm) | Bottom Plate Cxd (Mm) | Cc (Mm) | Natural Frequency Range (Hz) |
|---|---|---|---|---|---|---|---|
| RCD-E2-M16x2.0x150 | 96 | 112 | M16 | 232X207 | 271X176 | 241 | 3.5-11 |
| RCD-F2-M16x2.0x150 | 30-180 | 112 | M16 | 232X207 | 271X176 | 241 | 03-08 |
| RCD-F5-M16x2.0x150 | 183 | 112 | M16 | 232X207 | 271X176 | 241 | 3.5-11 |
| RCD-G1-M16x2.0x150 | 330 | 112 | M16 | 232X207 | 271X176 | 241 | 3.5-11 |
| RCD-G5-M16x2.0x150 | 471 | 112 | M16 | 232X207 | 271X176 | 241 | 3.5-11 |
| RCD-H2-M16x2.0x150 | 75-600 | 112 | M16 | 232X207 | 271X176 | 241 | 3.5-11 |
| RCD-H5-M16x2.0x150 | 630 | 112 | M16 | 232X207 | 271X176 | 241 | 3.5-11 |
| RCD-J2-M16x2.0x150 | 90-900 | 112 | M16 | 232X207 | 271X176 | 241 | 3.5-11 |
| RCD-K3-M16x2.0x150 | 600-2550 | 80 | M16 | 202X177 | 241X146 | 211 | 5.0-10 |
| RCD-L3-M16x2.0x150 | 150-1500 | 112 | M16 | 232X207 | 271X176 | 241 | 3.5-11 |
| RCD-N5-M16x2.0x150 | 1200-3600 | 112 | M16 | 232X207 | 271X176 | 241 | 3.5-11 |
| RCD-P3-M16x2.0x150 | 1500-4200 | 112 | M16 | 232X207 | 271X176 | 241 | 5.0-09 |
| RCD-P5-M16x2.0x150 | 750-2700 | 102 | M16 | 252X228 | 291X196 | 261 | 5.0-09 |
